點擊圖片查看大圖性能特點：Features:
廣泛適用于任何塑料原料的烘干，并可同時烘干不同材質、顏色的材料。尤其適合烘干對溫度精度要求高、用量少、多種顏色的材料。也適合于食品、制藥、電子、電鍍等行業預熱或干燥處理時使用。
Suitable for drying of all kinds of plastic raw materials; able to dry materials with different texture and color simultaneously, particularly for materials with high demand for temperature, in small quantities and wide colors; also suitable for other preheating or drying purpose, e.g. edible, medical, electronic and electroplating.
l 采用PI 溫度控制，精確控制干燥溫度。
l 集溫度、時間控制于一體，方便各種物料的干燥參數設定。
l 保溫材料、高密封設計，避免不必要的能量損耗。
l 可調式進口。
l 電機過載保護、相序保護。
l Adopted PI temperature control, precisely control drying temperature.
l Temperature and timer control in one unit, easy setting of drying parameters.
l Premium temperature insulating material, high airtight eliminating unnecessary energy consumption.
l Adjustable air inlet.
l Installed with current overload protector and phase controller.
工作原理：WORKING PRINCIPLE
將需烘干的物料放入活動料盤中，當接通電源運行時，強力風輪啟動迫使由進風口進入的空氣吹向電熱管，空氣經過電熱管加熱升溫，并穿過帶孔的隔墻，均勻吹向物料，攜帶了水分的空氣將由頂部的排濕風機抽出烤箱之外。如此反復循環則達到排濕、干燥之效果。
Place material on the movable trays; start the switch on power, strong wind wheel activated will blow air from the air inlet into the electric heating tube, hot air goes through the pored separated wall, and blows evenly on the material, moisture will be expelled by the dehumidification blower on the top. Moisture is expelled and material is dried through repeated process.
技術參數：
|
型號 |
功率 |
風輪馬達 |
溫控范圍℃ |
托盤數 |
容量 |
外形尺寸 |
凈重 |
|
model |
Power(kw) |
Blower(kw) |
Temperture range |
Numbers of tray |
Capacity(kg) |
Dimensions(cm) LxWxH |
Net weight(kg) |
|
XYDA-5 |
6 |
0.75 |
200 |
5 |
45 |
92x69x138 |
154 |
|
XYDA-9 |
6 |
0.75 |
200 |
9 |
80 |
92x69x175 |
190 |
|
XYDA-20 |
12 |
1.5 |
200 |
20 |
180 |
166x69x195 |
315 |
托盤尺寸/Tray Dimensions: 58x48x5cm，容量按尼龍6顆粒狀原料為標準/the capacity is based on testing of PA6 granule.
產品規格如有變更，恕不另行通知。We reserve right to change specifications without prior notice.
